B-63944EN-1/02 PROGRAMMING 5.COMPENSATION FUNCTION

- 141 -

Limitation

- Helical interpolation (G02, G03)

Tool offset cannot be specified in a block in which helical

interpolation is used.

- Coordinate system rotation (G68.1)

Coordinate system rotation is executed on the command program first,

followed by tool offset.

- Three-dimensional coordinate conversion (G68.1)

If tool offset is used, tool offset with coordinate shift cannot be used.

Offset with tool movement must be specified inside a nest of

three-dimensional coordinate conversion.

Example) G68.1 ... ;

T0101;

T0100;

G69.1 ... ;

- Workpiece coordinate system preset (G50.3)

Performing workpiece coordinate system preset causes tool offset with

tool movement to be canceled; this does not cause tool offset with

coordinate shift to be canceled.

- Machine coordinate system setting (G53), reference position return (G28), second,

third, and fourth reference position return (G30), floating reference position

return (G30.1), and manual reference position return

Basically, before performing these commands or operations, cancel

tool offset. These operations do not cause tool offset to be canceled.

The following actions take place:

When the command or

operation is specified

When the next axial

movement command is

specified

Tool

movement

The tool offset value is

temporarily canceled.

The tool offset value is

reflected.

Coordinate

shift

Coordinates with the tool

offset value reflected are

assumed.

Coordinates with the tool

offset value reflected are

assumed.
