B-63944EN-1/02 APPENDIX A.PARAMETERS

- 427 -

#7 #6 #5 #4 #3 #2 #1 #0

5431 MDL

[Input type] Parameter input

[Data type] Bit path

NOTE

When this parameter is set, the power must be

turned off before operation is continued.

# 0 MDL The G60 code (single direction positioning) is:

0: One-shot G code (group 00).

1: Modal G code (group 01).

#7 #6 #5 #4 #3 #2 #1 #0

HGO MGO

6000

[Input type] Parameter input

[Data type] Bit path

# 1 MGO When a GOTO statement for specifying custom macro control is

executed, a high-speed branch to 20 sequence numbers executed from

the start of the program is:

0: A high-speed branch is not caused to n sequence numbers from

the start of the executed program.

1: A high-speed branch is caused to n sequence numbers from the

start of the program.

# 4 HGO When a GOTO statement in a custom macro control command is

executed, a high-speed branch to the 30 sequence numbers

immediately before the executed statement is:

0: Not made.

1: Made.

#7 #6 #5 #4 #3 #2 #1 #0

6200 SKF

[Input type] Parameter input

[Data type] Bit path

# 7 SKF Dry run, override, and automatic acceleration/deceleration for G31

skip command

0: Disabled

1: Enabled
