FANUC Series 30i/31i/32i -A, 31i -A5

CANNED GRINDING CYCLE

(FOR GRINDING MACHINE)

WARNING

The G codes of the canned cycle (G71, G72, G73, and G74) (in case of

G code system C, G72, G73, G74, and G75) belong to the group 01 G

codes. The canned grinding cycle dose not have the cancel G code

such as G80 for the canned cycle for drilling. When a group 00 G code

except for G04 is specified, modal data such as depth of cut and so on

are cleared but the canned grinding cycle can not be canceled. To

cancel the canned grinding cycle, a group 01 G code except for G71,

G72, G73, and G74 must be specified. Therefore, when program is

executed the other command changing from the canned cycle for

grinding, a G code belongs to group 01 such as G00, G01 must be

specified to cancel the canned grinding cycle. If the program is executed

without canceling the canned cycle for grinding, the machine may

perform unexpected operation because the cycle is continued.

NOTE

1 The G code (G71, G72, G73, and G74) of the canned grinding cycle is

specified, while this cycle is valid, if G71, G72, G73, and G74 are not

specified in the command blocks after that, the canned grinding cycle is

executed according to the value of the A, B, W, U, I, and K which are

saved as the modal data.

Ex. G71 A_ B_ W_ U_ I_ K_ H_ ;

; <- Canned grinding cycle is executed by the empty block.

2 When changing to the canned grinding cycle from the canned cycle for

drilling, specify G80 to cancel the canned cycle.

3 When program executed to the other command changing from the

canned grinding cycle, according to the above-mentioned “WARNING”,

cancel the canned cycle.

4 Within the same path, the canned grinding cycle and the multiple

repetitive cycle cannot be specified at the same time. When both of the

optional function are vaild, select which function to use by the parameter

No.5105#0.
