B-63944EN-1/02 PROGRAMMING 5.COMPENSATION FUNCTION

- 143 -

5.1.7 Second Geometry Tool Offset

Overview

To compensate for a difference in tool attachment position or selection

position, this function adds second geometry tool offset to the X axis,

Y axis, and Z axis with all paths.

In contrast to this offset, the ordinary tool geometry offset is called the

first geometry tool offset.

It is possible to apply a tool offset value (tool wear offset + tool

geometry offset) in the reverse direction, using an appropriate signal.

This function may be used if the offset value differs even with a single

tool for a mechanical reason depending on the mounting position

(inside/outside) or the selected position (right/left).

NOTE

1. To use the second geometry tool offset, the

geometry and wear offset options are required.

2. To use the second geometry tool offset for the Y

axis, the Y axis offset option is required.

Format

• If parameter LGN (No. 5002#1) = 1

First geometry tool offset number or

first + second geometry tool offset numbers

;

Tool wear offset number

(M code that enables second geometry tool offset) ;

• If parameter LGN (No. 5002#1) = 0

T ;

Tool wear offset number + first geometry tool offset

number or wear + first + second geometry tool offset

numbers

(M code that enables second geometry tool offset) ;

Explanation

- Specification method

Offset using the second geometry tool offset is performed with a

program command.

Specify the second geometry tool offset with a T code command, and

using the second geometry tool offset signal G2SLC, specify whether

to set the offset value of the specified tool geometry offset number to

the first geometry tool offset only or to the first geometry tool offset

plus the second geometry tool offset. If using the first geometry tool

offset plus the second geometry tool offset, specify the axis to which

the second geometry tool offset is to be applied, using the appropriate

one of the second geometry tool offset axis select signal G2X, G2Z,

and G2Y.
