4.FUNCTIONS TO SIMPLIFY PROGRAMMING PROGRAMMING B-63944EN-1/02

- 74 -

Example

G71 P100 Q200 ...;

N100 ...;

...;

N200 ...;

G71 P300 Q400 ...;

N300 ...;

...;

N400 ...;

...;

G70 P100 Q200 ; (Executed without a search for

the first to third cycles)

G70 P300 Q400 ; (Executed after a search for the

fourth and subsequent cycles)

NOTE

The memory addresses of P and Q blocks stored

during rough cutting cycles by G71, G72, and G73

are erased after execution of G70.

All stored memory addresses of P and Q blocks

are also erased by a reset.

- Return to the cycle start point

In a finishing cycle, after the tool cuts the workpiece to the end point

of the target figure, it returns to the cycle start point in rapid traverse.

NOTE

The tool returns to the cycle start point always in

the nonlinear positioning mode regardless of the

setting of bit 1 (LRP) of parameter No. 1401.

Before executing a finishing cycle for a target figure

with a pocket cut by G71 or G72, check that the

tool does not interfere with the workpiece when

returning from the end point of the target figure to

the cycle start point.

- Tool nose radius compensation

Like G71, this cycle operation is performed according to the figure

determined by the tool nose radius compensation path when the offset

vector is 0 at start point A and start-up is performed in a block

between path A-A'.
