FANUC Series 30i/31i/32i -A, 31i -A5

CANNED GRINDING CYCLE

(FOR GRINDING MACHINE)

Explanations

The traverse grinding cycle consists of six operation sequences.

Operations (1) to (6) are repeated until the number of repetitions specified with address H. In

the single block stop mode, operations from (1) to (6) are performed at a time by one cycle

start.

• Operation sequences in the cycle

(1) Grinding wheel cutting

Cutting is performed along the X-axis in cutting feed mode to the depth specified by A (depth

of cut 1). The feedrate is specified by I.

(2) Dwell

Dwell is performed for the time specified by U.

(3) Grinding

Cutting feed is performed to the amount specified by W. The grinding axis is set by the

parameter No.5176. The feedrate is specified by K.

(4) Grinding wheel cutting

Cutting is performed along the X-axis in cutting feed mode to the amount specified by B

(depth of cut 2). The feedrate is specified by I.

(5) Dwell

Dwell is performed for the time specified by U.

(6) Grinding (return direction)

Cutting feed is performed in the reverse direction for the amount specified by W at a feedrate

specified by K.
