B-63944EN-1/02 PROGRAMMING 4.FUNCTIONS TO SIMPLIFY PROGRAMMING

- 55 -

Limitation

(1) For U(+), a figure for which a position higher than the cycle start

point is specified cannot be machined.

For U(-), a figure for which a position lower than the cycle start

point is specified cannot be machined.

(2) For type I, the figure must show monotone increase or decrease

along the first and second axes on the plane.

(3) For type II, the figure must show monotone increase or decrease

along the first axis on the plane.

- Start block

In the start block in the program for a target figure (block with

sequence number ns in which the path between A and A' is specified),

G00 or G01 must be specified. If it is not specified, alarm PS0065 is

issued.

When G00 is specified, cutting along path A-A' is performed in the

positioning mode. When G01 is specified, cutting along path A-A' is

performed in the linear interpolation mode.

In this start block, also select type I or II.

- Check functions

During cycle operation, whether the target figure shows monotone

increase or decrease is always checked.

NOTE

When tool nose radius compensation is applied,

the target figure to which compensation is applied

is checked.

The following checks can also be made.

Check Related parameter

Checks that a block with the sequence

number specified at address Q is contained

in the program before cycle operation.

Enabled when bit 2 (QSR) of

parameter No. 5102 is set to

Checks the target figure before cycle

operation.

(Also checks that a block with the sequence

number specified at address Q is contained.)

Enabled when bit 2 (FCK) of

parameter No. 5104 is set to
