4.2.5 End Face Peck Drilling Cycle (G74)

This cycle enables chip breaking in outer diameter cutting. If the

second axis on the plane (X-axis (U-axis) for the ZX plane) and

address P are omitted, operation is performed only along the first axis

on the plane (Z-axis for the ZX plane), that is, a peck drilling cycle is

performed.

Format

G74R (e) ;

G74X(U)_ Z(W)_ P(∆i) Q(∆k) R(∆d) F (f ) ;

e : Return amount

This designation is modal and is not changed until

the other value is designated. Also this value can be

specified by the parameter No. 5139, and the

parameter is changed by the program command.

X_,Z_ : Coordinate of the second axis on the plane (X-axis

for the ZX plane) at point B and

Coordinate of the first axis on the plane (Z-axis for

the ZX plane) at point C

U_,W_ : Travel distance along the second axis on the plane

(U for the ZX plane) from point A to B

Travel distance along the first axis on the plane (W

for the ZX plane) from point A to C

∆i : Travel distance in the direction of the second axis on

the plane (X-axis for the ZX plane)

∆k : Depth of cut in the direction of the first axis on the

plane (Z-axis for the ZX plane)

∆d : Relief amount of the tool at the cutting bottom

f : Feedrate

Unit

Diameter/radius

programming

Sign

Depends on the increment

system for the reference axis.

Radius programming

Not

required

∆i

Depends on the increment

system for the reference axis.

Radius programming

Not

required

∆k

Depends on the increment

system for the reference axis.

Radius programming

Not

required

∆d

Depends on the increment

system for the reference axis.

Radius programming NOTE 1

NOTE

1 Normally, specify a positive value for ∆d. When X

(U) and ∆i are omitted, specify a value with the sign

indicating the direction in which the tool is to

escape.

2 No decimal point can be input for P(∆i) and Q(∆k).
