B-63944EN-1/01 PROGRAMMING 2.PREPARATORY FUNCTION (G FUNCTION)

- 17 -

Table 2(a) G code list

G code system

A B C

Group Function

G50 G92 G92 Coordinate system setting or max. spindle speed clamp

G50.3 G92.1 G92.1

Workpiece coordinate system preset

- G50 G50 Scaling cancel

- G51 G51

Scaling

G50.1 G50.1 G50.1 Programmable mirror image cancel

G51.1 G51.1 G51.1

Programmable mirror image

G50.2

(G250)

G50.2

(G250)

G50.2

(G250)

Polygon turning cancel

G51.2

(G251)

G51.2

(G251)

G51.2

(G251)

Polygon turning

G52 G52 G52 Local coordinate system setting

G53 G53 G53 Machine coordinate system setting

G53.1 G53.1 G53.1

Tool axis direction control

G54

(G54.1)

G54

(G54.1)

G54

(G54.1)

Workpiece coordinate system 1 selection

G55 G55 G55 Workpiece coordinate system 2 selection

G56 G56 G56 Workpiece coordinate system 3 selection

G57 G57 G57 Workpiece coordinate system 4 selection

G58 G58 G58 Workpiece coordinate system 5 selection

G59 G59 G59

Workpiece coordinate system 6 selection

G60 G60 G60 00 Single direction positioning

G61 G61 G61 Exact stop mode

G62 G62 G62 Automatic corner override mode

G63 G63 G63 Tapping mode

G64 G64 G64

Cutting mode

G65 G65 G65 00 Macro call

G66 G66 G66 Macro modal call A

G66.1 G66.1 G66.1 Macro modal call B

G67 G67 G67

Macro modal call A/B cancel

G68 G68 G68 04 Mirror image on for double turret or balance cutting mode

G68.1 G68.1 G68.1

Coordinate system rotation start or 3-dimensional coordinate

conversion mode on

G68.2 G68.2 G68.2

Feature coordinate system selection

G69 G69 G69 04 Mirror image off for double turret or balance cutting mode cancel

G69.1 G69.1 G69.1 17

Coordinate system rotation cancel or 3-dimensional coordinate

conversion mode off

G70 G70 G72 Finishing cycle

G71 G71 G73 Stock removal in turning

G72 G72 G74 Stock removal in facing

G73 G73 G75 Pattern repeating cycle

G74 G74 G76 End face peck drilling cycle

G75 G75 G77 Outer diameter/internal diameter drilling cycle

G76 G76 G78 Multiple-thread cutting cycle

G72.1 G72.1 G72.1 Figure copy (rotation copy)

G72.2 G72.2 G72.2

Figure copy (parallel copy)
