B-63944EN-1/02 PROGRAMMING 6.MEMORY OPERATION BY Series 15 FORMAT

- 317 -

- Example

Suppose parameter No. 1022 is set so that U, V, and W are the parallel

axes of X, Y, and Z, respectively.

G17 G81 ...... Z _ _: Drilling axis is Z axis.

G17 G81 ...... W _ _: Drilling axis is W axis.

G18 G81 ...... Y _ _: Drilling axis is Y axis.

G18 G81 ...... V _ _: Drilling axis is V axis.

G19 G81 ...... X _ _: Drilling axis is X axis.

G19 G81 ...... U _ _: Drilling axis is U axis.

G17, G18, and G19 may be specified in a block in which G73 to G89

are not present.

CAUTION

Before switching between drilling axes, cancel

canned cycles.

NOTE

The Z-axis can always be used as the drilling axis

by setting FXY (bit 0 of parameter No.5101). When

FXY is 0, the Z-axis is always used as the drilling

axis.

- Specification of point R

In the Series 16/18 command format, the distance from the initial level

to point R is specified using an incremental value during specification

of point R.

In the Series 15 command format, the specification method depends

on RAB (bit 6 of parameter No. 5102). When RAB = 0, an

incremental value is always used for specification. When RAB = 1 for

G code system A, an absolute value is used for specification. When

RAB = 1 for G code system B, C, an absolute value is used in G90

mode while an incremental value is used in G91 mode.

Series 15 command format

Series16/18

command

format

Parameter RAB (No.5102#6) = 1 RAB=0

G code

system A

G code system B,C

G90 G91

Absolute

Incremental

- Diameter/radius programming

The diameter/radius specification of canned cycles for drilling R

command in the series 15 command format can be matched with the

diameter/radius specification of the drilling axis by setting RDI (bit 7

of parameter No.5102) to 1.
