SAFETY PRECAUTIONS B-63944EN-2/02

s-6

1.3 WARNINGS AND CAUTIONS RELATED TO

PROGRAMMING

This section covers the major safety precautions related to

programming. Before attempting to perform programming, read the

supplied User’s Manual carefully such that you are fully familiar with

their contents.

WARNING

1 Coordinate system setting

If a coordinate system is established incorrectly,

the machine may behave unexpectedly as a result

of the program issuing an otherwise valid move

command. Such an unexpected operation may

damage the tool, the machine itself, the workpiece,

or cause injury to the user.

2 Positioning by nonlinear interpolation

When performing positioning by nonlinear

interpolation (positioning by nonlinear movement

between the start and end points), the tool path

must be carefully confirmed before performing

programming. Positioning involves rapid traverse. If

the tool collides with the workpiece, it may damage

the tool, the machine itself, the workpiece, or

cause injury to the user.

3 Function involving a rotation axis

When programming polar coordinate interpolation

or normal-direction (perpendicular) control, pay

careful attention to the speed of the rotation axis.

Incorrect programming may result in the rotation

axis speed becoming excessively high, such that

centrifugal force causes the chuck to lose its grip

on the workpiece if the latter is not mounted

securely. Such mishap is likely to damage the tool,

the machine itself, the workpiece, or cause injury to

the user.

4 Inch/metric conversion

Switching between inch and metric inputs does not

convert the measurement units of data such as the

workpiece origin offset, parameter, and current

position. Before starting the machine, therefore,

determine which measurement units are being

used. Attempting to perform an operation with

invalid data specified may damage the tool, the

machine itself, the workpiece, or cause injury to the

user.
