FANUC Series 30i/31i/32i -A, 31i -A5

CANNED GRINDING CYCLE

(FOR GRINDING MACHINE)

Limitations

• Cutting axis

The cutting axis is the first controlled axis. If the parameter FXY (No.5101#0) is set to 1, the

cutting axis can be changed by plane selection command (G17, G18, and G19).

• Grinding axis

The axis number of the grinding axis is selected by the parameter No.5179 , except for the

cutting axis. The grinding command is always specified by W regardless of the axis name.

Incidentally, it is possible to specify by the axis name correspond to the setting axis number,

too.

• P

When P is specified except by P1 to P4, the skip function is not valid.

P is valid only in the block in which it is specified.

• B

When B is not specified , it is assumed to be B=A.

B is valid only in the block in which it is specified.

• A, B, W

A, B, and W must all be specified in incremental mode.

When A and B are not specified or A=B=0 are specified, spark-out (only move to the

direction of grinding) is performed.

• H

When H is not specified or H=0 are specified, it is assumed to be H=1.

H is valid only in the block in which it is specified.

• Clear

A, W, U, and K in canned cycles are modal data common to G71, G72, G73, and G74. They

remain valid until new data is specified. They are cleared when a group 00 G code ecept for

G04 or a group 01 G code except for G71, G72, G73, and G74 is specified. P, B and H are

valid only in the block in which they are specified.

• B codes

During the canned cycle, B codes (second auxiliary codes) cannot be specified.

NOTE

1 An alarm (PS0455) is issued when the grinding axis command is not

specified in the block in which G74 is specified.

2 An alarm (PS0456) is issued when the cutting axis number and the

grinding axis number are the same.

3 While this cycle is valid, if G90 (absolute command) is specified, A, B,

and W are regarded as incremental command.

4 When P1 to P4 are specified without the multistage skip option, an

alarm (PS0370) is issued.
