B-63944EN-1/02 PROGRAMMING 3.INTERPOLATION FUNCTION

- 27 -

3.4 TORQUE LIMIT SKIP (G31 P99)

With the motor torque limited (for example, by a torque limit

command, issued through the PMC window), a move command

following G31 P99 (or G31 P98) can cause the same type of cutting

feed as with G01 (linear interpolation).

With the issue of a signal indicating a torque limit has been reached

(because of pressure being applied or for some other reason), a skip

occurs.

For details of how to use this function, refer to the manuals supplied

by the machine tool builder.

Format

G31 P99 IP _ F_ ;

G31 P98 IP _ F_ ;

G31 : One-shot G code (G code effective only in the block in

which it is issued)

Explanation

- G31 P99

If the motor torque limit is reached, or a SKIP signal is received

during execution of G31 P99, the current move command is aborted,

and the next block is executed.

- G31 P98

If the motor torque limit is reached during execution of G31 P98, the

current move command is aborted, and the next block is executed. The

SKIP signal <X0004#7/Path 2 X0013#7> does not affect G31 P98.

Entering a SKIP signal during the execution of G31 P98 does not

cause a skip.

- Torque limit command

If a torque limit is not specified before the execution of G31 P99/98,

the move command continues; no skip occurs even if a torque limit is

reached.

- Custom macro system variable

When G31 P99/98 is specified, the custom macro variables hold the

coordinates at the end of a skip.

If a SKIP signal causes a skip with G31 P99, the custom macro system

variables hold the coordinates based on the machine coordinate system

when it stops, rather than those when the SKIP signal is entered.
