B-63944EN-1/02 PROGRAMMING 5.COMPENSATION FUNCTION

- 235 -

5.8 AUTOMATIC TOOL OFFSET (G36, G37)

When a tool is moved to the measurement position by execution of a

command given to the CNC, the CNC automatically measures the

difference between the current coordinate value and the coordinate

value of the command measurement position and uses it as the offset

value for the tool. When the tool has been already offset, it is moved

to the measurement position with that offset value. If the CNC judges

that further offset is needed after calculating the difference between

the coordinate values of the measurement position and the

commanded coordinate values, the current offset value is further

offset.

Refer to the instruction manuals of the machine tool builder for

details.

Explanation

- Coordinate system

When moving the tool to a position for measurement, the coordinate

system must be set in advance. (The workpiece coordinate system for

programming is used in common.)

- Movement to measurement position

A movement to a measurement position is performed by specifying as

follows in the MDI, or MEM mode :

G36 Xxa ; or G37 Zza ;

In this case, the measurement position should be xa or za (absolute

programming).

Execution of this command moves the tool at the rapid traverse rate

toward the measurement position, lowers the feedrate halfway, then

continues to move it until the approach end signal from the measuring

instrument is issued.

When the tool tip reaches the measurement position, the measuring

instrument outputs the measurement position reach signal to the CNC

which stops the tool.

- Offset

The current tool offset value is further offset by the difference

between the coordinate value (α or β) when the tool has reached the

measurement position and the value of xa or za specified in G36Xxa

or G37Zza.

Offset value x = Current offset value x+(α-xa)

Offset value z = Current offset value z+(β-za)

xa : Programmed X-axis measurement point

za : Programmed Z-axis measurement point

These offset values can also be altered from the MDI keyboard.
