A.PARAMETERS APPENDIX B-63944EN-1/02

- 420 -

Return in multiple repetitive turning canned cycles G74 and G75

5139

[Input type] Parameter input

[Data type] Real path

[Unit of data] mm, inch (input unit)

[Minimum unit of data] Depend on the increment system of the reference axis

[Valid data range] 0 or positive 9 digit of minimum unit of data (refer to the standard

parameter setting table (B) )

(When the increment system is IS-B, 0.0 to +999999.999)

This parameter sets the return in multiple repetitive turning canned

cycles G74 and G75.

NOTE

Specify a radius value at all times.

Minimum depth of cut in the multiple repetitive turning canned cycle G76

5140

[Input type] Parameter input

[Data type] Real path

[Unit of data] mm, inch (input unit)

[Minimum unit of data] Depend on the increment system of the reference axis

[Valid data range] 0 or positive 9 digit of minimum unit of data (refer to the standard

parameter setting table (B) )

(When the increment system is IS-B, 0.0 to +999999.999)

This parameter sets a minimum depth of cut in the multiple repetitive

turning canned cycle G76 so that the depth of cut does not become too

small when the depth of cut is constant.

NOTE

Specify a radius value at all times.

Finishing allowance in the multiple repetitive turning canned cycle G76

5141

[Input type] Parameter input

[Data type] Real path

[Unit of data] mm, inch (input unit)

[Minimum unit of data] Depend on the increment system of the reference axis

[Valid data range] 0 or positive 9 digit of minimum unit of data (refer to the standard

parameter setting table (B) )

(When the increment system is IS-B, 0.0 to +999999.999)

This parameter sets the finishing allowance in multiple repetitive

turning canned cycle G76.

NOTE

Specify a radius value at all times.
