A.PARAMETERS APPENDIX B-63944EN-1/02

- 390 -

Profile of a chuck

1330

[Input type] Parameter input

[Data type] Byte path

[Valid data range] 0 to 1

Select a chuck figure.

0 : Chuck which holds a workpiece on the inner surface

1 : Chuck which holds a workpiece on the outer surface

Dimensions of the claw of a chuck (L)

1331

[Input type] Parameter input

[Data type] Real path

[Unit of data] mm, inch (input unit)

[Minimum unit of data] Depend on the increment system of the applied axis

[Valid data range] 0 or positive 9 digit of minimum unit of data (refer to the standard

parameter setting table (B) )

(When the increment system is IS-B, 0.0 to +999999.999)

Set the length (L) of the claw of the chuck.

NOTE

Whether to specify this parameter by using a

diameter value or radius value depends on whether

the corresponding axis is based on diameter

programming or radius programming.
