PROGRAMMING

9. PRESSING FUNCTION

B–63124EN/01

N100G00G90X x

Y y

;

N110M12;

N120X x

Y y

T ;

N130X x

Y y

;

N140X x

Y y

;

N150X x

Y y

;

N160X x

Y y

;

N170X x

Y y

;

N180M13;

(1)The first punch point of nibbling is commanded in the block next to

M12. A T code can also be commanded in this block concurrently.

The first punch point (x

, y

) of nibbling is previously commanded

in N120 block, and nibbling is started when the positioning to (x

) has been completed and the motion corresponding to the T code

has been finished.

The movement amounts along the X-axis and Y-axis in this block are

not restricted by the maximum positioning distances (parameter Nos.

16188, 16184) of the X-axis and Y-axis in the nibbling mode.

(2)In the blocks after the first punch point of nibbling has been

commanded, the positioning command is given to correspond to the

pitches by G68 and G69 commands.

If the movement amounts along the X-axis and Y-axis in these blocks

exceed the parameter set values (parameter Nos. 16188, 16189), alarm

(No. 4521) results.

In N130 to N170 blocks, the positioning corresponding to the

nibbling pitch is commanded. If the movement amounts along

X-axis x

-x

, x

-x

, x

-x

, x

-x

, x

-x

or the movement amounts

of Y-axis y

-y

, y

-y

, y

-y

, y

-y

, y

-y

exceed the parameter set

values in each block, alarm (No. 4521) is issued.

(3)M13 is commanded in the block next to the block where the last punch

point of nibbling was commanded.

The last punch point (x

, y

) of nibbling is commanded in the N170

block and M13 is commanded in the next block, i.e. in block N180.

Punching is done at (x

, y

) and nibbling terminates.

The G00 command in the nibbling mode is given to execute the

positioning to the commanded position, and the movement amounts

along X-axis and Y-axis should not exceed the parameter set values (No.

16188: for millimeter input, No. 16189: for inch input, except for the

command to the first punch point of nibbling.

9.4.1

G00 Command in

Nibbling Mode

Example4
