PROGRAMMING

15. COMPENSATION FUNCTION

B–63124EN/01

236

Tool compensation values can be entered into CNC memory from the

MDI panel (see section III–8.1) or from a program.

A tool compensation value is selected from the CNC memory when the

corresponding code is specified after address D in a program.

The value is used for cutter compensation.

Table 15.3 shows the valid input range of tool compensation values.

Table15.3 The valid input range of tool compensation value

Increment system

Geometric compensation value

Increment

system

Metric input Inch input

IS–A "9999.99 mm "999.999inch

IS–B "999.999 mm "99.9999inch

The memory can hold 32, 64, 99, 200, or 400 tool compensation values

(option).

Address D is used in the program.

The range of the number that comes after the address D depens on the

number of tool compensation values : 0 to 32, 0 to 64, 0 to 99, 0 to 200,

or 0 to 400.

P : Number of tool compensation

R : Tool compensation value in the absolute command(G90) mode

Value to be added to the specified tool compensation value in the

incremental command(G91) mode (the sum is also a tool

compensation value.)

G10L11P_R_ ;

NOTE

To provide compatibility with the format of older CNC

programs, the system allows L1 to be specified instead of

L11.

15.3

TOOL

COMPENSATION

VALUES, NUMBER

OF COMPENSATION

VALUES, AND

ENTERING VALUES

FROM THE

PROGRAM (G10)

Explanations

D Valid range of tool

compensation values

D Number of tool

compensation values

and the addresses to be

specified

Format

D Input of tool

compensation value

by programing
