OPERATION

10. CREATING PROGRAMS

B–63124EN/01

566

When no keys are pressed, the standard details screen is displayed.

PROGRAM O0010 N00000

STANDARD FORMAT

G G G G

X Y

I J

P Q

R F

M S

T D

L H

;

EDIT **** *** *** 11:55:13

[ PRGRM ][ ][ G.MENU ][ BLOCK ][ (OPRT) ]

7 Move the cursor to the block to be modified on the program screen.

At this time, a data address with the cursor blinks.

8 Enter numeric data by pressing the numeric keys and press the

[INPUT] soft key or

INPUT

key. This completes the input of one data

item.

9 Repeat this operation until all data required for the entered G code is

entered.

10 Press the

INSERT

key. This completes the registration of data of one

block in program memory. On the screen, the G code menu screen is

displayed, allowing the user to enter data for another block. Repeat

the procedure starting with 5 as required.

11 After registering all programs, press the

[PRGRM] soft key. The

registered programs are converted to the converssational format and

displayed.

12 Press the

RESET

key to return to the program head.
