Series 16i/18i/160i/180i - PA Operators manual Page 628

Operators manual
OPERATION
11. SETTING AND DISPLAYING DATA
B–63124EN/01
618
5 For absolute programming, enter the data and press the [INPUT]
soft key.
For incremental programming, enter an increment or decrement
and press the [+INPUT] soft key.
Sub-tool registration data items to be entered are as follows:
(a) Sub-tool number
Specify sub-tool numbers used for controlling multiple tools. Up to
64 numbers can be specified. Settings range from 0 to 99.
(b)Angle
Specify angles used for indexing the turret for sub-tools. Settings
range from –359999 to +359999.
(c) Y-axis offset
Specify tool position compensation for sub-tools along the Y-axis in
the machine coordinate system. Settings range from –99999999 to
+99999999.
When the optional graphics function is used, the figures of sub-tools
registered to the tool number registration screen for multiple tools (see
Item 11.4.3.6) can be specified. These figures are drawn with the graphics
function.
(1)Displaying the screen
1 Press the
OFFSET
SETTING
function key.
2 Press the
menu key several times until the [M.TOOL] soft
key appears.
3 Press the [M.TOOL] soft key. Then press the [M.FIGURE] to
display the tool figure registration screen for multiple tools.
MULTI TOOL (SHAPE) O0010 N00000
NO. SHAPE(C) SIZE(I) SIZE(J) ANGLE(K)
001 01 10000 0 0
002 01 10000 0 0
003 01 30000 0 0
004 02 20000 10000 0
005 02 22000 10000 0
006 02 21000 9000 0
007 01 15000 0 0
008 01 12000 0 0
009 03 16000 8000 0
010 03 16000 10000 0
>_
MDI **** *** *** 13:53:13
[ SHAPE ][ M.TOOL ][ ][ ][ (OPRT) ]
Fig. 11.4.3.7 Tool figure registration screen for multiple tools
The number indicated on the screen corresponds to the tool registration
number on the tool registration screen for multiple tools (see Item
11.4.3.6).
11.4.3.7
Displaying and setting
items on the tool figure
registration screen for
multiple tools (for
drawing figures)
