OPERATION

B–63124EN/01

2. OPERATIONAL DEVICES

373

Five types of external input/output devices are available. This section

outlines each device. For details on these devices, refer to the

corresponding manuals listed below.

Table 2.4 External I/O device

Device name Usage Max.

storage

capacity

Reference

manual

FANUC Handy File Easy–to–use, multi function

input/output device. It is de-

signed for FA equipment

and uses floppy disks.

3600m B–61834E

FANUC Floppy

Cassette

Input/output device. Uses

floppy disks.

2500m B–66040E

FANUC FA Card Compact input/output de-

vice. Uses FA cards.

160m B–61274E

FANUC PPR Input/output device consist-

ing of a paper tape reader,

tape punch, and printer.

275m B–58584E

Portable Tape Reader Input device for reading pa-

per tape.

______ Appendix H

The following data can be input/output to or from external input/output

devices:

1. Programs

2. Offset data

3. Parameters

4. Custom macro common variables

For how data is input and output, see Chapter 8.

2.4

EXTERNAL I/O

DEVICES
