Series 16i/18i/160i/180i - PA Operators manual Page 467

Operators manual

Page of 756

/ 756

OPERATION

B–63124EN/01

6. SAFETY FUNCTIONS

457

(1)The workpiece holder area (parameter Nos. 16505 to 16516) of the

safety zone function is used.

(2)The tool area (parameter Nos. 16517 to 16532, 16551 to 16558) of the

safety zone function is used.

NOTE

1 This function is optional.

2 The optional safety zone function must be specified at the

same time.

3 The operation of this function is based on the safety zone

function. So, see the specification of the safety zone

function.

4 If the workpiece holder area is specified as a punch

forbidden area (parameter No. 16501, SZj) according to the

type B specification, a check is made before axis

movement, even when the positioning and press–off

command (G70) is specified.

6.6.2

Tool/Workpiece Holder

Areas

6.6.3

Note
