Series 16i/18i/160i/180i - PA Operators manual Page 752

Operators manual
B–63124EN/01
Index
i–3
Function keys and soft keys, 352
Functions to simplify programming, 139
[G]
G00 command in nibbling mode, 96
G01, G02, and G03 commands in nibbling mode, 97
G53,G28,G30,G30.1 and G29 commands in cutter
compensation C mode, 224
General screen operations, 352
Glossary, 714
Graphic display, 341
Graphic display screen and drawing, 654
Graphics function, 646
Grid (G78, G79), 146
[H]
Heading a program, 536
Helical interpolation (G02, G03), 41
Help function, 659
High speed cutting functions, 310
How to indicate command dimensions for moving the
tool – absolute, incremental commands, 16
How to view the position display change without run-
ning the machine, 334
[I]
Inch/metric conversion (G20, G21), 79
Increment system, 25, 319
Incremental command just after pattern function, 153
Incremental feed, 386
Input command from MDI, 223
Inputting a program, 470
Inputting and outputting floppy files, 506
Inputting and outputting offset data, 503
Inputting and outputting parameters, 501
Inputting and outputting parameters and pitch error
compensation data, 476
Inputting and outputting programs, 496
Inputting custom macro common variables, 480
Inputting offset data, 474
Inputting parameters, 476
Inputting pitch error compensation data, 478
Inputting tool data, 490
Inputting/outputting custom macro common variables,
480
Inputting/outputting tool data, 490
Inserting a word, 537
Inserting altering and deleting a word, 533
Inside–corner override (G62), 52
Interference check, 217
Internal circular cutting feedrate change, 54
Interpolation functions, 30
Interruption type custom macro, 297
[J]
Jog feed, 384
[K]
Key input and input buffer, 370
[L]
Line at angle (G76), 144
Linear and circular punch command, 179
Linear interpolation (G01), 33
Linear nibbling (G69), 91
Linear punch command (G45), 179
List of functions and tape format, 678
Local coordinate system, 74
Look–ahead control (G08), 312
[M]
M command for switching the punching and laser
modes, 119
Machine coordinate system, 69
Machine lock and auxiliary function lock, 428
Macro call, 165, 275
Macro call using an M code, 283
Macro call using G code, 282
Macro function, 164
Macro statements and NC statements, 270
Macro storage capacity, 167
Manual absolute on, 389
Manual continuous feed, incremental feed, manual
reference point return, 319
