Series 16i/18i/160i/180i - PA Operators manual Page 702

Operators manual
APPENDIX
B–63124EN/01
G. ALARM LIST
695
Number ContentsMessage
086 DR SIGNAL OFF When entering data in the memory by using Reader / Puncher interface,
the ready signal (DR) of reader / puncher was off.
Power supply of I/O unit is off or cable is not connected or a P.C.B. is de-
fective.
087 BUFFER OVERFLOW When entering data in the memory by using Reader / Puncher interface,
though the read terminate command is specified, input is not interrupted
after 10 characters read. I/O unit or P.C.B. is defective.
088 LAN FILE TRANS ERROR
(CHANNEL–1)
File data transfer via OSI–ETHERNET has been stopped due to a trans-
fer error.
089 LAN FILE TRANS ERROR
(CHANNEL–2)
File data transfer via OSI–ETHERNET has been stopped due to a trans-
fer error.
090 REFERENCE RETURN INCOM-
PLETE
The reference position return cannot be performed normally because
the reference position return start point is too close to the reference posi-
tion or the speed is too slow. Separate the start point far enough from
the reference position, or specify a sufficiently fast speed for reference
position return.
091 REFERENCE RETURN
INCOMPLETE
Manual reference position return cannot be performed when automatic
operation is halted.
100 PARAMETER WRITE ENABLE On the PARAMETER(SETTING) screen, PWE(parameter writing en-
abled) is set to 1. Set it to 0, then reset the system.
101 PLEASE CLEAR MEMORY The power turned off while rewriting the memory by program edit opera-
tion. If this alarm has occurred, press <RESET> while pressing
<PROG>, and only the program being edited will be deleted.
Register the deleted program.
109 FORMAT ERROR IN G08 A value other than 0 or 1 was specified after P in the G08 code, or no
value was specified.
110 DATA OVERFLOW The absolute value of fixed decimal point display data exceeds the al-
lowable range. Modify the program.
111 CALCULATED DATA OVERFLOW The result of calculation is out of the allowable range (–10
47
to –10
–29
,
0, and 10
–29
to 10
47
).
112 DIVIDED BY ZERO Division by zero was specified. (including tan 90°)
113 IMPROPER COMMAND A function which cannot be used in custom macro is commanded.
Modify the program.
114 FORMAT ERROR IN MACRO There is an error in other formats than <Formula>.
Modify the program.
115 ILLEGAL VARIABLE NUMBER A value not defined as a variable number is designated in the custom
macro or in high–speed cycle cutting.
The header contents are improper in a high–speed cycle cutting. This
alarm is given in the following cases:
1. The header corresponding to the specified machining cycle
number called is not found.
2. The cycle connection data value is out of the allowable range
(0 – 999).
3. The number of data in the header is out of the allowable range
(0 – 32767).
4. The start data variable number of executable format data is out of
the allowable range (#20000 – #85535).
5. The storing data variable number of executable format data is
out of the allowable range (#85535).
6. The storing start data variable number of executable format
datais overlapped with the variable number used in the header.
Modify the program.
116 WRITE PROTECTED VARIABLE The left side of substitution statement is a variable whose substitution
is inhibited. Modify the program.
