OPERATION

B–63124EN/01

11. SETTING AND DISPLAYING DATA

605

Cutter compensation values are specified by D codes in a program.

Compensation values corresponding to D codes are displayed or set on the

screen.

Procedure for setting and displaying the cutter compensation value

1 Press function key

OFFSET

SETTING

2 Press chapter selection soft key

[OFFSET] or press

OFFSET

SETTING

several

times until the tool compensation screen is displayed.

The screen varies according to the type of tool offset memory.

OFFSET O0001 N00000

NO. DATA NO. DATA

001 1.000 009 0.000

002 –2.000 010 –7.500

003 0.000 011 12.000

004 5.000 012 –20.000

005 0.000 013 0.000

006 0.000 014 0.000

007 0.000 015 0.000

008 0.000 016 0.000

ACTUAL POSITION (RELATIVE)

X 0.000 Y 0.000

C 0.000

> _

MDI **** *** *** 16:05:59

[ OFFSET ][SETING][ WORK ][ ][ (OPRT) ]

3 Move the cursor to the compensation value to be set or changed using

page keys and cursor keys, or enter the compensation number for the

compensation value to be set or changed and press soft key

[NO.SRH].

4 To set a compensation value, enter a value and press soft key

[INPUT].

To change the compensation value, enter a value to add to the current

value (a negative value to reduce the current value) and press soft key

[+INPUT]. Or, enter a new value and press soft key [INPUT].

11.4.1

Setting and Displaying

the Tool Offset Value

Procedure
