OPERATION

B–63124EN/01

8. DATA INPUT/OUTPUT

489

For the numeral input in the data input area with FILE NO. and

PROGRAM NO., only lower 4 digits become valid.

When the data protection key on the machine operator’s panel is ON, no

programs are read from the floppy. They are verified against the contents

of the memory of the CNC instead.

No. Contents

An invalid file number or program number was entered.

(Specified program number is not found.)

Verification operation found a mismatch between a program

loaded into memory and the contents of the floppy

The dataset–ready signal (DR) for the input/output device is

turned off. (The no file error or duplicate file error occurred on

the input/output device because an invalid file number, pro-

gram number, or file name was entered.
