Series 16i/18i/160i/180i - PA Operators manual Page 589

Operators manual
OPERATION
B–63124EN/01
11. SETTING AND DISPLAYING DATA
579
The current position of the tool in the relative coordinate system can be
reset to 0 or preset to a specified value as follows:
Procedure to set the axis coordinate to a specified value
1 Enter an axis address (such as X or Y) on the screen for the relative
coordinates. The indication for the specified axis blinks and the soft
keys change as shown on the left.
2 ⋅ To reset the coordinate to 0, press soft key
[ORGIN]. The relative
coordinate for the blinking axis is reset to 0.
⋅ To preset the coordinate to a specified value, enter the value and
press soft key [PRESET]. The relative coordinate for the blinking
axis is set to the entered value.
Procedure to reset all axes
1 Press soft key [(OPRT)].
2 Press soft key
[ORIGIN].
3 Press soft key [ALLEXE].
The relative coordinates for all axes are reset to 0.
Bits 6 and 7 of parameter 3104 can be used to select whether the displayed
values include cutter compensation.
Bit 3 of parameter 3104 is used to specify whether the displayed positions
in the relative coordinate system are preset to the same values as in the
workpiece coordinate system when a coordinate system is set by a G92
command or when the manual reference position return is made.
On the 7.2″/8.4″ LCD or 9.5″/10.4″ LCD, only the coordinates for the first
to fifth axes are displayed initially whenever when there are six or more
controlled axes. Pressing the
[ABS] soft key displays the coordinates for
the sixth and subsequent axes.
Explanations
D Setting the relative
coordinates

ORIGIN
246.912
Y 913.780
C 578.246
>X
MEM
PRESET
X

ORIGIN
EXEC
RELABS
ALL
(OPRT)
ALLEXE
D Display including
compensation values
D Presetting by setting a
coordinate system
D Displaying the sixth and
subsequent axes
