APPENDIX

B–63124EN/01

E. STATUS WHEN TURNING POWER ON,

WHEN CLEAR AND WHEN RESET

691

Item ResetClearedWhen turning power on

Output

signals

CNC alarm signal AL Extinguish if there is no

cause for the alarm

Extinguish if there is no

cause for the alarm

Extinguish if there is no

cause for the alarm

Reference position

return completion LED

× f

(× : Emergency stop)

S, T and B codes × f f

M code × × ×

M, S and T strobe sig-

nals

× × ×

Spindle revolution sig-

nal (S analog signal)

× f f

CNC ready signal MA ON f f

Servo ready signal SA ON (When other than ser-

vo alarm)

ON (When other than ser-

vo alarm)

ON (When other than

servo alarm)

Cycle start LED (STL) × × ×

Feed hold LED (SPL) × × ×

NOTE

1 When heading is performed, the main program number is

displayed.

2 When a reset is performed during execution of a

subprogram, control returns the head of main program by

heading function.

Execution cannot be started from the middle of the

subprogram.
