Series 16i/18i/160i/180i - PA Operators manual Page 708

Operators manual
APPENDIX
B–63124EN/01
G. ALARM LIST
701
6) Background edit alarm
Number Message Contents
??? BP/S alarm BP/S alarm occurs in the same number as the P/S alarm that occurs in
ordinary program edit.
140 BP/S alarm It was attempted to select or delete in the background a program being
selected in the foreground. (Note)
Use background editing correctly.
NOTE
Alarm in background edit is displayed in the key input line
of the background edit screen instead of the ordinary alarm
screen and is resettable by any of the MDI key operation.
7) Absolute pulse coder (APC) alarm
Number Message Contents
300 nth–axis origin return Manual reference position return is required for the nth–axis (n=1 to 8).
301 APC alarm: nth–axis communication nth–axis (n=1 to 8) APC communication error. Failure in data transmis-
sion
Possible causes include a faulty APC, cable, or servo interface module.
302 APC alarm: nth–axis over time nth–axis (n=1 to 8) APC overtime error.
Failure in data transmission.
Possible causes include a faulty APC, cable, or servo interface module.
303 APC alarm: nth–axis framing nth–axis (n=1 to 8) APC framing error. Failure in data transmission.
Possible causes include a faulty APC, cable, or servo interface module.
304 APC alarm: nth–axis parity nth–axis (n=1 to 8) APC parity error.
Failure in data transmission.
Possible causes include a faulty APC, cable, or servo interface module.
305 APC alarm: nth–axis pulse error nth–axis (n=1 to 8) APC pulse error alarm.
APC alarm.APC or cable may be faulty.
306 APC alarm: nth–axis battery voltage
0
nth–axis (n=1 to 8) APC battery voltage has decreased to a low level so
that the data cannot be held.
APC alarm. Battery or cable may be faulty.
307 APC alarm: nth–axis battery low 1 nth–axis (n=1 to 8) axis APC battery voltage reaches a level where the
battery must be renewed.
APC alarm. Replace the battery.
308 APC alarm: nth–axis battery low 2 nth–axis (n=1 to 8) APC battery voltage has reached a level where the
battery must be renewed (including when power is OFF).
APC alarm .Replace battery.
309 APC ALARM:
n AXIS ZRN IMPOSSIBL
Return to the origin has been attempted without first rotating the motor
one or more times. Before returning to the origin, rotate the motor one
or more times then turn off the power.
8) Serial pulse coder (SPC) alarms
No. Message Description
360 n AXIS : ABNORMAL CHECKSUM
(INT)
A checksum error occurred in the built–in pulse coder.
361 n AXIS : ABNORMAL PHASE DATA
(INT)
A phase data error occurred in the built–in pulse coder.
362 n AXIS : ABNORMAL REV.DATA
(INT)
A rotation speed count error occurred in the built–in pulse coder.
