Series 16i/18i/160i/180i - PA Operators manual Page 659

Operators manual

Page of 756

/ 756

OPERATION

B–63124EN/01

12. GRAPHICS FUNCTION

649

Specify the parameters for graphic drawing.

(1)Procedure

1 Press the function key

GRAPH

. The graphic parameter setting screen

appears. If it does not appear, press the soft key [PARA].

GRAPHIC PARAMETER O1234 N00200

AXES ( 0,1,2,3,4 ) P= 0

RANGE (MAX.)

X= 1150000 Y= 700000 Z= 0

RANGE (MIN.)

X= –100000 Y= –100000 Z= 0

SCALE K= 10

GRAPHIC CENTER

X= 525000 Y= 300000 Z= 0

PROGRAM STOP N= 0

AUTO ERASE A= 1

MEM **** *** *** 16:19:18

[ PARAM ][ GRAPH ][ ][ ][ ]

Fig. 12.3(a) Graphic parameter setting screen

GRAPHIC PARAMETER O1234 N00200

START POINT

X= 0 Y= 0 Z= 0

WORK LENGTH

X= 1100000 Y= 650000

RAPID PATH

(1:ON 0:OFF) P= 0

HOLDER POSITION HOLDER LENGTH

X1= 300000 X= 40000 Y= 20000

X2= 700000 X= 40000 Y= 20000

MEM **** *** *** 16:23:21

[ PARAM ][ GRAPH ][ ][ ][ ]

Fig. 12.3(b) Graphic parameter setting screen

2 Move the cursor to the parameter to be changed by pressing the

cursor keys.

3 Enter new data and press the

INPUT

key.

The parameters are described below:

12.3

SPECIFYING

DRAWING

PARAMETERS
