PROGRAMMING

13. PROGRAM CONFIGURATION

B–63124EN/01

136

The program number is an eight–digit number prefixed with the letter O

(O00000001 to O99999999).

It is possible to disable editing subprograms identified using program

numbers O00008000 to O00008999, O00009000 to O00009999,

O80000000 to O89999999, and O90000000 to O99999999.

Parameter Program number for uneditable program

NE8 (No. 3202#0) O00008000 to O00008999

NE9 (No. 3202#4) O00009000 to O00009999

P8E (No. 3204#3) O80000000 to O89999999

P9E (No. 3204#4) O90000000 to O99999999

NOTE

If an incorrect password is specified, it becomes impossible

to set the NE9 (bit 3 of parameter No. 3202) and PQE (bit

4 of parameter No. 3204) parameters.

To output a program by specifying a range, the name of the output file is

determined as follows:

O00000001–G: If output as O00000001 or O00123456.

O12345678–G: If output as O12345678 or O12345678.

It is possible to change a special subprogram number according to the

SPR parameter (bit 5 of parameter No. 3204).

1) Macro call using a G code

Parameter for

Program number

setting a G code

If SPR = 0 If SPR = 1

No. 6050 O00009010 O90009010

No. 6051 O00009011 O90009011

No. 6052 O00009012 O90009012

No. 6053 O00009013 O90009013

No. 6054 O00009014 O90009014

No. 6055 O00009015 O90009015

No. 6056 O00009016 O90009016

No. 6057 O00009017 O90009017

No. 6058 O00009018 O90009018

No. 6059 O00009019 O90009019

13.4

EIGHT–DIGIT

PROGRAM NUMBER

Explanations

D Uneditable programs

D File name

D Special program
