OPERATION

11. SETTING AND DISPLAYING DATA

B–63124EN/01

622

When the optional safety zone check function is used, the current safety

zone can be displayed and changed.

(1)Displaying the screen

1 Press the

OFFSET

SETTING

function key.

2 Press the menu key several times until the [SAFETY] soft

key appears.

3 Press the [SAFETY] soft key to display the safety zone setting

screen.

SAFETY ZONE (ABSOLUTE) O0017 N01234

AREA #1 AREA #3

X2= 100.000 X2= 1000.000

X1= 200.000 X1= 1150.000

Y = 100.000 Y = 110.000

AREA #2 AREA #4

X2= 500.000 X2= 1400.000

X1= 600.000 X1= 1550.000

Y = 100.000 Y = 110.000

TOOL ZONE

X = 5.000

Y = 10.000

MEM **** *** *** 11:32:41

[ TOOL ][ ][ SAFETY ][ ][ (OPRT) ]

Fig. 11.4.4 Safety zone setting screen

The safety zone is displayed in the workpiece coordinate system. By

setting MDP, bit 0 of parameter No. 16502, the zone can be displayed in

the machine coordinate system.

(2)Setting items from the MDI

By setting SZI, bit 4 of parameter No. 16502, data for safety zones can

be changed.

1 Set the mode to MDI.

2 Display the safety zone setting screen by following the steps

described in (1).

3 Move the cursor to the safety zone data to be changed with the

cursor keys.

4 For absolute programming, enter the data and press the [INPUT]

soft key.

For incremental programming, enter an increment or decrement

and press the [+INPUT] soft key.

Safety zone data is as follows:

11.4.4

Displaying and Setting

Items on the Safety

Zone Setting Screen
