PROGRAMMING

16. CUSTOM MACRO

B–63124EN/01

258

Procedure for displaying variable values

1 Press the

OFFSET

SETTING

key to display the tool compensation screen.

2 Press the continuous menu key

3 Press the soft key

[MACRO] to display the macro variable screen.

4 Enter a variable number, then press soft key

[NO.SRH].

The cursor moves to the position of the entered number.

VARIABLE O1234 N12345

NO. DATA NO. DATA

100 123.456 108

101 0.000 109

102 110

103 111

104 112

105 113

106 114

107 115

ACTUAL POSITION (RELATIVE)

X 0.000 Y 0.000

Z 0.000 B 0.000

MEM **** *** *** 18:42:15

[ MACRO ] [ MENU ] [

OPR ] [ ] [ (OPRT) ]

⋅ When the value of a variable is blank, the variable is null.

⋅ The mark ******** indicates an overflow (when the absolute

value of a variable is greater than 99999999) or an underflow (when

the absolute value of a variable is less than 0.0000001).

Program numbers, sequence numbers, and optional block skip numbers

cannot be referenced using variables.

Example:

Variables cannot be used in the following ways:

O#1;

/#2G00X100.0;

N#3Y200.0;

D Displaying variable

values

Procedure


