PROGRAMMING

16. CUSTOM MACRO

B–63124EN/01

260

Table 16.2 (c) System variable for macro alarms

Variable

number

Function

#3000 When a value from 0 to 200 is assigned to variable #3000,

the NC stops with an alarm. After an expression, an alarm

message not longer than 26 characters can be described.

The CRT screen displays alarm numbers by adding 3000 to

the value in variable #3000 along with an alarm message.

Example:

#3000=1(TOOL NOT FOUND);

→ The alarm screen displays “3001 TOOL NOT FOUND.”

Time information can be read and written.

Table 16.2 (d) System variables for time information

Variable

number

Function

#3001 This variable functions as a timer that counts in 1–millisecond

increments at all times. When the power is turned on, the value

of this variable is reset to 0. When 65535 milliseconds is

reached, the value of this timer returns to 0.

#3002 This variable functions as a timer that counts in 1–hour incre-

ments when the cycle start lamp is on. This timer preserves its

value even when the power is turned off. When 1145324.612

hours is reached, the value of this timer returns to 0.

#3011 This variable can be used to read the current date (year/month/

day). Year/month/day information is converted to an apparent

decimal number. For example, March 28, 1993 is represented

as 19930328.

#3012 This variable can be used to read the current time (hours/min-

utes/seconds). Hours/minutes/seconds information is con-

verted to an apparent decimal number. For example, 34 min-

utes and 56 seconds after 3 p.m. is represented as 153456.

The control state of automatic operation can be changed.

Table 16.2 (e) System variable (#3003) for automatic operation control

#3003

Single block Completion of an auxiliary

function

0 Enabled To be awaited

1 Disabled To be awaited

2 Enabled Not to be awaited

3 Disabled Not to be awaited

S When the power is turned on, the value of this variable is 0.

S When single block stop is disabled, single block stop operation is not

performed even if the single block switch is set to ON.

D Macro alarms

D Time information

D Automatic operation

control
