Series 16i/18i/160i/180i - PA Operators manual Page 737

Operators manual
APPENDIX
I. GLOSSARY
B–63124EN/01
730
Term Description
Start–up Tool movement when cutter compensation is started in offset cancel mode.
Status display Displaying the status of the CNC operation.
Storage of macro Registering a macro by placing the U address, followed by a two–digit num-
ber, before two or more block commands to be stored, and by closing the
commands with a V address followed by the same two–digit number used
with the U address.
Stored stroke check Setting a forbidden area in the CNC for a tool, decelerating the tool to a stop,
and issuing an alarm if the tool is about to enter the forbidden area.
Stored stroke limit (See “Stored stroke check.”)
Stroke limit check before move Stroke limit check performed before the movement specified in a block is
started.
Subprogram Program that can be called repeatedly by the control section of another pro-
gram.
Superposition control (Two–path control
function)
Two–path control in which a move command for an axis in one of the paths is
superimposed on an axis in the other path.
Synchronization control (Two–path con-
trol function)
Two–path control in which a move command for an axis in one of the paths is
used to control an axis in the other path so that they are synchronized.
Synchronous operation Operation in which an axis is controlled using a move command for another
axis so that both axes are synchronized. This is used to machine extremely
large workpieces that extend over two tables.
System variable Macro variable used to read or write CNC data, such as a tool offset value
and current position.
[T]
T code Coded number, following the T address, that specifies a tool function.
T command neglect Ignoring T commands. This function is enabled by supplying an ignore T
command signal to the CNC.
T function Specifying a tool or data related to the specified tool.
T–axis control In a turret punch press machine, causing the CNC to calculate the required
amount of movement relative to the current turret position and the turret posi-
tion corresponding to a T command, thereby indexing the turret.
Tandem control Control in which two motors are used to drive a single axis. This is used to
drive, for example, a table that would be too large for a single motor to supply
sufficient torque.
Tangential speed constant control Maintaining a constant feedrate tangential to the tool path.
Tape code Information interchange code used for numerical control.
Tape end Symbol indicating the end of a program file.
Tape start Symbol indicating the beginning of a program file.
Tapping mode
?? mixture of continuous threading and
???
Operation mode in which the tool moves to the next block without being
decelerated at the end of the current block. Cutting feedrate override and
feed hold are disable in this operation mode.
TEACH IN HANDLE mode TEACH–IN mode where the manual operation is manual handle feed.
TEACH IN JOG mode TEACH–IN mode where the manual operation is jog feed.
TEACH IN mode Mode used to store information about the position of a controlled axis,
obtained by manual operation, into the CNC memory for program creation.
Test operation Confirming that a program operates as intended.
