PROGRAMMING

11. TOOL FUNCTION

(T FUNCTION)

B–63124EN/01

108

Tool offset is applicable to respective T codes in the X-axis and Y-axis

directions.

Since use of this tool offset function depends upon machine tool builders,

refer to the machine tool builder’s manual.

WARNING

1 Tool offset compensation applies to tools numbered from 1

to 9999.

2 Tool offset values are set in the tool registering screen in the

unit of the least command increment for each X axis and Y

axis before shipment of the machine from the machine tool

builder’s factory.

3 If data are inputted by inch in a millimeter system machine,

or if data are inputted by millimeter in an inch system

machine, a tool offset error is produced within the sum of

a half of the least input increment and half of the least

command increment. This error is not accumulated.

11.3

TOOL OFFSET
