OPERATION

B–63124EN/01

8. DATA INPUT/OUTPUT

519

Code Meaning

102 The memory card does not have sufficient free space.

105 No memory card is mounted.

106 A memory card is already mounted.

110 The specified directory cannot be found.

111 There are too many files under the root directory to allow a

directory to be added.

114 The specified file cannot be found.

115 The specified file is protected.

117 The file has not yet been opened.

118 The file is already open.

119 The file is locked.

122 The specified file name is invalid.

124 The extension of the specified file is invalid.

129 A non–corresponding function was specified.

130 The specification of a device is invalid.

131 The specification of a pathname is invalid.

133 Multiple files are open at the same time.

135 The device is not formatted.

140 The file has the read/write disabled attribute.

The size of the memory card to be used must be larger than that of the

RAM module mounted in the CNC. The size of the RAM module can be

determined from the system configuration screen.

Use a memory card that conforms to PCMCIA Ver. 2.0, or JEIDA Ver. 4.1.

A memory card which has no attribute memory, or no device information

in its attribute memory, cannot be used.

Data saved to a memory card is compatible only with CNCs that have the

same hardware configuration and the same option configuration.

A flash ROM card can be used only for data loading.

During automatic operation, the contents of a memory card cannot be

displayed, formatted, or deleted. To enable these operations, therefore,

stop or suspend automatic operation.

File system error codes

Restrictions

D Memory card size

D Memory card

specifications

D Attribute memory

D Compatibility of saved

data

D Flash ROM card

D Operation during

automatic operation
