Series 16i/18i/160i/180i - PA Operators manual Page 259

Operators manual

Page of 756

/ 756

PROGRAMMING

15. COMPENSATION FUNCTION

B–63124EN/01

248

When a tool with a rotation axis (C–axis) is moved in the XY plane during

cutting, the normal direction control function can control the tool so that

the C–axis is always perpendicular to the tool path (Fig. 15.6 (a)).

Tool

Programmed tool path

Normal direction (in

which the tool moves)

C–axis

Fig15.6 (a) Sample Movement of the tool

G code

Function Explanation

G41.1 or G151

Normal direction

control left

If the workpiece is to the right of the

tool path looking toward the direc-

tion in which the tool advances,

the normal direction control left

(G41 1 or G151) function is s

eci

G42.1 or G152

Normal direction

control right

(G41

G151)

function

s eci

fied.

After G41.1 (or G151) or G42.1 (or

G152) is specified, the normal

direction control function is en-

abled (normal direction control

G40.1 or G150

Normal direction

control cancel

abled

(normal

direction

control

mode).

When G40.1 (or G150) is speci-

fied, the normal direction control

mode is canceled.

15.6

NORMAL DIRECTION

CONTROL

(G40.1, G41.1, G42.1

OR G150, G151,

G152)

 
