11. SETTING AND DISPLAYING DATA
587
Displays the program currently being executed in MEMORY or MDI
mode.
Procedure for displaying the program contents
1 Press function key
PROG
to display a current position display screen.
2 Press chapter selection soft key
[PRGRM].
The cursor is positioned at the block currently being executed.
MEM STRT *** FIN 15:08:47
[ PRGRM ][ CHECK ][CURRNT][NEXT][ (OPRT) ]
PROGRAM O1000 N00210
N130 X1085. Y635. ;
N140 X15. Y635. ;
N200 G72 X150. Y80. ;
N300 G72 X400. Y80. ;
N310 G76 I40. J0 K7 ;
N400 G72 X770. Y80. ;
N410 G76 I40. J0. K4 ;
N500 G72 X50. Y200. ;
N510 G76 I40. J90. K8 T02 ;
N600 G72 X1050. Y200. ;
PRGRM
N210 G76 I40.J0 K4 T03 ;
On the 9.5″/10.4″ LCD, the contents of the program are displayed on the
right half of the screen or on the entire screen (switched each time soft key
[PRGRM] is pressed).
PROGRAM
O0006 N00000
+
O0003 ;
G65 H01 P#2001 O0 ;
G65 H01 P#2014 O0 ;
G65 H01 P#2110 O0 ;
G04 P2000 ;
G04 P2000 ;
G04 P2000 ;
G65 H01 P#2001 O50000 ;
G65 H01 P#2014 O60000 ;
G65 H01 P#2110 O30000 ;
G04 P2000 ;
G04 P2000 ;
G04 P2000 ;
G65 H02 P#2001 O#2001 R3 ;
G65 H03 P#2014 O15000 R#2014
;
G65 H04 P#2110 O3 R#2110 ;
G65 H01 P#100 O#3901 ;
G65 H01 P#101 O#3902 ;
G65 H01 P#3901 O#102 ;
G65 H01 P#3902 O#103 ;
G04 P5000 ;
G04 P5000 ;
G04 ;
G65 H01 P#100 O#4001 ;
G65 H01 P#101 O#4002 ;
/ G65 H01 P#102 O#4003 ;
G65 H01 P#103 O#4004 ;
G65 H01 P#104 O#4005 ;
G65 H01 P#105 O#4006 ;
G65 H01 P#106 O#4007 ;
G65 H01 P#107 O#4008 ;
G65 H01 P#108 O#4009 ;
EDIT **** *** ***
07:12:55
O SRH SRH= SRHO
REWIND
11.2.1
Program Contents
Display Screen
Procedure
Explanations
D 9.5″/10.4″ LCD
Previous page
Next page
