Series 16i/18i/160i/180i - PA Operators manual Page 160

Operators manual

Page of 756

/ 756

PROGRAMMING

B–63124EN/01

14. FUNCTIONS TO SIMPLIFY

PROGRAMMING

149

The punching method is as follows.

1 Punch the first point.

2 Set the pitch to 0.95 w

3 Calculate

ȏ–w

0.95 w

= n

If n v1, the pitch shall be “ȏ – w

”. If n is an integer, the pitch shall

be 0.95 w

When n is not an integer, [n] + 1 = n’: [ ] shows that the decimal place

is omitted.

And

ȏ–w

n’

shall be the pitch.

At this time, there is a small calculation error of nearly 0.01 mm n’,

but this error is compensated at the last punching.

That is, the last pitch shall be X

n’

–X

n’–1

4 According to the above method, the pitch is always as follows.

0.45 w

x p x 0.95 w

5 Length ȏ must be; ȏ y 1.5w
