OPERATION

9. EDITING PROGRAMS

B–63124EN/01

556

Unlike ordinary programs, custom macro programs are modified,

inserted, or deleted based on editing units.

Custom macro words can be entered in abbreviated form.

Comments can be entered in a program.

Refer to the section 10.1 for the comments of a program.

When editing a custom macro already entered, the user can move the

cursor to each editing unit that starts with any of the following characters

and symbols:

(a) Address

(b) # located at the start of the left side of a substitution statement

(d) First character of IF, WHILE, GOTO, END, DO, POPEN, BPRNT,

DPRNT and PCLOS

On the CRT screen, a blank is placed before each of the above characters

and symbols.

(Example) Head positions where the cursor is placed

001 X–#100 ;

#1 =123 ;

N002 /2 X[12/#3] ;

N003 X–SQRT[#3/3*[#4+1]] ;

N004 X–#2 Z#1 ;

N005 #5 =1+2–#10 ;

IF[#1NE0] GOTO10 ;

WHILE[#2LE5] DO1 ;

#[200+#2] =#2*10 ;

#2 =#2+1 ;

END1 ;

When a custom macro word is altered or inserted, the first two characters

or more can replace the entire word.

Namely,

WHILE → WH GOTO → GO XOR → XO AND → AN

SIN → SI COS → CO TAN → TA ATAN → AT

SQRT → SQ ABS → AB BCD → BC BIN → BI

FIX → FI FUP → FU ROUND → RO END → EN

POPEN → PO BPRNT → BP DPRNT → DP PCLOS→PC

(Example) Keying in

WH [AB [#2 ] LE RO [#3 ] ]

has the same effect as

WHILE [ABS [#2 ] LE ROUND [#3 ] ]

The program is also displayed in this way.

9.7

EDITING OF CUSTOM

MACROS

Explanations

D Editing unit

D Abbreviations of custom

macro word
