Series 16i/18i/160i/180i - PA Operators manual Page 730

Operators manual

Page of 756

/ 756

APPENDIX

B–63124EN/01

I. GLOSSARY

723

Term Description

Manual handle feed Feeding a specified controlled axis by rotating the handle to generate com-

mand pulses.

Manual handle interruption Manual handle feed performed during automatic operation, in such a way that

the manual–feed amount is added to the automatic–feed amount.

Manual intervention Pausing automatic operation and starting manual operation.

Manual numeric command Feeding a controlled axis in jog mode by executing the data specified in pro-

gram form.

Manual operation Feeding a controlled axis manually.

Manual per revolution feed Jog feed in which the feedrate is obtained by multiplying the feedrate per rota-

tion, set in the CNC, by the spindle speed. Used to override the jog feedrate.

Manual pressing Manual control in which the operator presses a button on the machine opera-

tor’s panel to start punching.

Manual pulse generator Unit that converts rotation to pulse train when its handle is rotated manually.

Used for manual handle speed.

Manual rapid traverse Feeding a controlled axis at the rapid traverse rate in jog mode.

Manual reference position return Manual feeding a specified controlled axis to a reference position.

Master axis Axis for which move commands can be specified during synchronous opera-

tion.

Maximum Stroke Maximum range of movement that can be controlled by the CNC or PMC.

MDI mode Mode in which MDI operation is possible.

MDI operation Automatic operation based on a program input to the CNC from the MDI key-

board. The program is erased upon the completion of MDI operation.

Memory mode Mode in which memory operation can be performed.

Memory operation Automatic operation based on a program previously stored into CNC memory.

Menu switch Use of the CRT/MDI, LCD/MDI or PDP/MDI panel to emulate some switches

on the machine operator’s panel.

Mirror images Inverting an incremental value for a programmed dimension word along a

specified coordinate axis from positive to negative, or vice versa, with respect

to a specified reference point.

Miscellaneous function Auxiliary function Specifying start or stop of the spindle, or the end of a program. Spindle and

tool functions may sometimes be included, in which case the term auxiliary

function is used.

Modal call Calling a custom macro program (once an instruction to call it is specified)

each time a block having an axis movement command is executed. The call-

ing is repeated until the call instruction is canceled.

Modal G code G code which, once issued, remains valid until another G code in the same

group is issued.

Mode Holding a specified function in the CNC. For example, once a cutter com-

pensation preparatory function is issued, the CNC stays in the state in which

cutter compensation is possible until a cutter compensation cancel prepara-

tory function is issued (cutter compensation mode).

Mode selection Selecting an operation mode.

Move command calling Calling a specific custom program from a block containing a move command,

after the move command has been executed.

Multi–edit function Displaying two programs side–by–side so that they can be edited simulta-

neously.
