Series 16i/18i/160i/180i - PA Operators manual Page 73

Operators manual

Page of 756

/ 756

PROGRAMMING

5. FEED FUNCTIONS

B–63124EN/01

Dwell G04 X_ ; or G04 P_ ;

X_ : Specify a time (decimal point permitted)

P_ : Specify a time (decimal point not permitted)

By specifying a dwell, the execution of the next block is delayed by the

specified time. In addition, a dwell can be specified to make an exact

check in the cutting mode (G62 mode).

When neither P nor X is specified, exact stop is performed.

Table 5.5 (a) Command value range of the dwell time (Command by X)

Increment system

Command value range Dwell time unit

IS–A

0.01 to 999999.99

IS–B

0.001 to 99999.999

Table 5.5 (b) Command value range of the dwell time (Command by P)

Increment system

Command value range Dwell time unit

IS–A 1 to 99999999 0.01 s

IS–B 1 to 99999999 0.001 s

5.5

DWELL (G04)

Format

Explanations
