PROGRAMMING

14. FUNCTIONS TO SIMPLIFY

PROGRAMMING

B–63124EN/01

148

G86I ȏ J θ P w

Q w

;

With the current position or the coordinates designated by G72 as a start

point, this function allows to punch length ȏ in the direction of angle θ

for the X-axis, using a rectangular tool with w

as the width and w

as the

length.

ȏ : The unit of this length is the input unit.

In the case of negative, perform punching operation in a symmetrical

direction at the starting point as its center.

θ : The angle for the X-axis is fixed in integers in increments of 0.01

degrees.

The counterclockwise direction corresponds to positive.

, w

: Tool profile size __ the unit conforms to the input unit. For

positive and negative, punch the left and right sides in the forward

direction, respectively. Both w

and w

must be designated when

either positive or negative. For a square tool with w

= w

, w

may

be omitted.

45°

100

G72G90X10.0Y5.0 ;

G86I100.0J45.0P10.0Q8.0;

ȏ–W

+++

’–1

’

G72G90X5.0Y10.0 ;

G86I80.0J0P-10.0 ;

14.1.6

Share Proofs (G86)

Examples
