PROGRAMMING

B–63124EN/01

17. PROGRAMMABLE DATA

ENTRY (G10)

309

G10L30; Tool data entry mode setting

N_P_R_; Tool data entry

G11; Tool data entry mode cancel

N_ : Tool data No. or multiple tool data No. +200

P01: Tool No. or multi–tool No. setting

P02: Turret position or angle for indexing turret of multiple tool

setting

P03: X–axis tool offset setting

P04: Y–axis tool offset setting

P05: Tool change No. setting

P06: Punch count setting

P07: Tool life setting

P08: Tool figure setting for graphic operation

P09: X dimension of a tool setting for graphic operation

P10: Y dimension of a tool setting for graphic operation

P11 : Tool angle setting for graphic operation

R_ : Tool data setting value

  

Change the value of tool number for the tool data No. 10.

G10L30 ; Tool data entry mode s

N10P01R333 ; Modify tool number

G11 ; Tool data entry mode cancel

17.2

TOOL DATA ENTRY

Format

Examples
