Series 16i/18i/160i/180i/160is/180is - Model A Parameter manual Page 201

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63010EN/02
194
NOTE
1 To use the fourth serial spindle, the third serial spindle is
required.
2 The fourth serial spindle can be used just in Series 16i.
OR4 For the fourth serial spindle, the function for controlling the spindle
orientation of the stop position external setting type is:
0 : Not used.
1 : Used.
NOTE
The fourth serial spindle can be used just in Series 16i.
SSS Synchronous spindle control by each spindle is:
0 : Not performed.
1 : Performed.
The master axis and slave axis of synchronous spindle control can be
selected from the first to fourth spindles.
The target spindle of synchronous spindle control is specified in
parameters No. 4831 to 4834.
In addition, the following signals affect the control.
Synchronous spindle signal of each spindle
SPSYC1 to SPSYC4 <G288 bits 0 to 3>
Signal of synchronous control of the spindle phase for each spindle
SPPHS1 to SPPHS4 <G289 bits 0 to 3>
NOTE
The fourth spindle can be used just in Series 16i.
SSY Simple synchronous spindle control by each spindle is:
0 : Not performed.
1 : Performed.
The master axis and slave axis of simple synchronous spindle control can
be selected from the first to fourth spindles.
The target spindle of simple synchronous spindle control is set in
parameters No. 4821 to No. 4824.
In addition, the following signals affect the control.
Signal of simple synchronous control of each spindle
ESSYC1 to ESSYC4 <G264 bits 0 to 3>
Parking signal of simple synchronous control of each spindle
PKESE1 to PKESE4 <G265 bits 0 to 3>
NOTE
The fourth serial spindle can be used just in Series 16i.
