#7
8200
#6 #5 #4 #3
AZP
#2
AZR
#1 #0
AAC
NOTE
When this parameter is set, the power must be turned off
before operation is continued.
[Data type] Bit
AAC
0 : Does not perform angular axis control.
1 : Performs inclined axis control.
AZR
0 : The machine tool is moved along the Cartesian axis during manual
reference position return along the slanted axis under angular axis
control.
1 : The machine tool is not moved along the Cartesian axis during
manual reference position return along the slanted axis under angular
axis control.
AZP When an angular axis moves, the reference position return completion
signal for the Cartesian axis, ZPx <F094, F096, F098, F100, or F116>, is:
0 : Not cleared.
1 : Cleared.
#7
ADG8201
#6 #5 #4 #3 #2
AO3
#1
AO2
#0
AOT
[Data type] Bit
AOT When angular axis control is enabled, the values indicating the area for
stored stroke check 1 (parameters Nos. 1320 and 1321) are treated as:
0 : Coordinates in the angular coordinate system.
1 : Coordinates in the Cartesian coordinate system.
AO2 When angular axis control is enabled, the values indicating the area for
stored stroke check 2 (parameters Nos. 1322 and 1323) are treated as:
0 : Coordinates in the angular coordinate system.
1 : Coordinates in the Cartesian coordinate system.
AO3 When angular axis control is enabled, the values indicating the area for
stored stroke check 3 (parameters Nos. 1324 and 1325) are treated as:
0 : Coordinates in the angular coordinate system.
1 : Coordinates in the Cartesian coordinate system.
ADG The contents of diagnostic data Nos. 306 and 307 are:
0 : Not swapped. The angular axis and Cartesian axis are displayed in
this order.
1 : Swapped. The Cartesian axis and angular axis are displayed in this
order.
