4. DESCRIPTION OF PARAMETERS
B–63010EN/02
24
NOTE
When a self–loop test is performed, specify the same
value in parameters No.0171 and No.0172.
0173 Station address in M–NET
NOTE
When this parameter is set, the power must be turned off
before operation is continued.
[Data type] Byte
[Valid range] 1 to 15
Specify a station address in the serial interface.
0174 Baud rate in M–NET
NOTE
When this parameter is set, the power must be turned off
before operation is continued.
[Data type] Byte
[Valid range] 0 to 6 (The standard setting is 3.)
Specify a baud rate for the serial interface.
Setting Baud rate (bps)
1 2400
2 4800
3 9600
4 19200
5 38400
6 57600
7 76800
0175 Time required for connecting two stations in M–NET
NOTE
When this parameter is set, the power must be turned off
before operation is continued.
[Data type] Word
[Unit of data] ms
[Valid range] 1 to 32767 (The standard setting is 10000.)
Specify a time limit from when the connection sequence is completed for
the self–station to when the normal transfer sequence starts in the serial
interface.
