LZE If L (number of hob threads) = 0 is specified at the start of EGB

synchronization:

0 : Synchronization is started, assuming that L = 1 is specified.

1 : Synchronization is not started, assuming that L = 0 is specified.

However, helical gear compensation is performed.

JHD While the C–axis and hob axis are synchronized with each other (in the

G81 mode), jogging and handle feeds around the C–axis are

0 : Disabled

1 : Enabled

DLY Compensating C–axis servo delay with G84 is

0 : Disabled

1 : Enabled

7702

PHD

PHS

#5 #4 #3

ART

#2 #1 #0

TDP

[Data type] Bit

TDP The specifiable number of teeth, T, of the simple electronic gearbox is:

0 : 1 to 1000

1 : 0.1 to 100 (1/10 of a specified value).

NOTE

In either case, a value from 1 to 1000 can be specified.

ART The retract function executed when an alarm is issued is:

0 : Disabled.

1 : Enabled.

When an alarm is issued, the tool is retracted at the specified feedrate by

the specified amount of travel.

(Parameters Nos. 7750 and 7751)

NOTE

If a servo alarm is issued for an axis along which the tool is

not retracted, servo motor activation is kept until completion

of retraction.

PHS When the G81/G80 block contains no R command:

0 : Acceleration/deceleration is not performed at EGB synchronization

start/cancellation.

1 : Acceleration/deceleration is performed at EGB synchronization

start/cancellation. After acceleration/deceleration at synchronization

start, phase synchronization is automatically performed.

PHD Direction of movement for automatic EGB phase synchronization

0 : Positive (+) direction

1 : Negative (–) direction
