4.DESCRIPTION OF PARAMETERS B-63950EN/02
- 132 -
3019
Address to which the PMC axis control skip signal and the measurement
position arrival signal are assigned
NOTE
When this parameter is set, the power must be
turned off before operation is continued.
[Input type] Parameter input
[Data type] Word path
[Valid data range] 0 to 727
Set an X address to which the PMC axis control skip signal ESKIP
and the measurement position arrival signals (XAE, YAE, and ZAE
(M series) or XAE and ZAE (T series)) are to be assigned.
Example 1. When No.3012 is set to 5 and No.3019 is set to 6
When XSG (bit 2 of parameter No. 3008) is 1, the PMC axis control skip signal, and
measurement position arrival signal are allocated to X0006 and the skip signal is
allocated to X0005.
#7 #6 #5 #4 #3 #2 #1 #0
X005 SKIP SKIP6 SKIP5 SKIP4 SKIP3 SKIP2 SKIP8 SKIP7
(T series)
#7 #6 #5 #4 #3 #2 #1 #0
SKIP SKIP6 SKIP5 SKIP4 SKIP3 SKIP2 SKIP8 SKIP7
(M series)
#7 #6 #5 #4 #3 #2 #1 #0
X006 ESKIP -MIT2 +MIT2 -MIT1 +MIT1 ZAE XAE
(T series)
#7 #6 #5 #4 #3 #2 #1 #0
ESKIP ZAE YAE XAE
(M series)
Example 2. When No.3012 is set to 5 and No.3019 is set to 5
When XSG (bit 2 of parameter No. 3008) is 1, the PMC axis control skip signal,
measurement position arrival signal, and skip signal are allocated to X0005.
#7 #6 #5 #4 #3 #2 #1 #0
X005 ESKIP -MIT2 +MIT2 -MIT1 +MIT1 ZAE XAE
SKIP
SKIP6 SKIP5 SKIP4 SKIP3 SKIP2 SKIP8 SKIP7
(T series)
#7 #6 #5 #4 #3 #2 #1 #0
ESKIP ZAE YAE XAE
SKIP
SKIP6
SKIP5 SKIP4 SKIP3
SKIP2 SKIP8 SKIP7
(M series)
NOTE
This parameter is valid when bit 2 (XSG) of
parameter No. 3008 is set to 1.
Depending on the option configuration of the I/O
Link, the actually usable X addresses are:
X0 to X127, X200 to X327, X400 to X527, X600 to
X727
